Chinfa DRA18-12 | 12V 18W Power Supply
£20.42
AC-DC PSU. Power: 18W Input: 90-264 Vac Output: 12 Vdc
DRA18-12 from Chinfa, 12 Vdc 18 W ac-dc DIN-rail for industrial control applications.
Featuring universal input, protected outputs and a wider 18 W performance range.
13 in stock (can be backordered)
Description
The Chinfa DRA18-12 is a compact DIN rail power supply designed for industrial automation, machinery and control-panel applications. This spring-clamp terminal version delivers a regulated 12VDC output at up to 1.5A, providing 18W of continuous output power.
A universal 90 to 264VAC input range, internal input filtering and compact 22.5mm-wide housing make the DRA18-12 well suited to space-constrained industrial installations.
The plastic enclosure mounts directly onto a standard 35mm DIN rail and includes integrated protection against short circuit and overcurrent conditions.
Chinfa DRA18-12 12V 1.5A DIN Rail Power Supply
A compact 18W industrial AC-DC power supply with universal input, regulated 12VDC output and spring-clamp terminals.
The DRA18-12 converts a single-phase AC or compatible high-voltage DC input into a stable 12VDC supply for industrial control and automation equipment. Its 1.5A output capacity makes it suitable for sensors, relays, instrumentation, communications equipment and other low-power 12VDC loads.
Typical Applications
The Chinfa DRA18-12 is suitable for applications including:
- Industrial automation and machinery
- PLC and remote I/O systems
- Sensors, relays and control equipment
- Process-control instrumentation
- Industrial communications equipment
- Security and access-control systems
- Compact 12VDC control panels
Universal AC and DC Input
The power supply accepts a wide 90 to 264VAC input and can also operate from a compatible 120 to 375VDC source, supporting installation across common industrial supply systems without manual voltage selection.
18W Regulated Output
The DRA18-12 delivers a nominal 12VDC output at up to 1.5A, providing 18W of continuous power for industrial loads.
Compact 22.5mm Housing
With a width of only 22.5mm, the DRA18-12 is ideal for control cabinets where DIN rail space is limited.
Spring-Clamp Terminals
This version uses spring-clamp terminals for quick, secure and maintenance-friendly field wiring. The model is supplied without the A suffix, distinguishing it from the screw-terminal DRA18-12A version.
Internal Input Filter
An integrated input filter helps reduce conducted electrical noise and supports reliable operation in industrial environments.
Integrated Protection
Short-circuit and overcurrent protection help safeguard the power supply and connected equipment during abnormal operating conditions.
Key Features
The principal electrical, protection and installation characteristics of the Chinfa DRA18-12.
- Model: DRA18-12
- Terminal type: Spring-clamp terminals
- AC input voltage: 90 to 264VAC
- DC input voltage: 120 to 375VDC
- Nominal output voltage: 12VDC
- Maximum output current: 1.5A
- Rated output power: 18W
- Typical efficiency: 77%
- Ripple and noise: Approximately 50mV peak-to-peak
- Protection: Short circuit and overcurrent
- Cooling: Natural convection
- Operating temperature: -20 to +71°C
- Enclosure: Plastic
- Mounting: 35mm DIN rail
- Dimensions: 90 x 22.5 x 114mm
- Weight: Approximately 150g
- Warranty: 3 years
Technical Specification
Electrical, protection, environmental and mechanical information for product selection and system design.
| Specification | Details |
|---|---|
| Manufacturer | Chinfa Electronics |
| Model Number | DRA18-12 |
| Series | DRA18 |
| Product Type | Industrial DIN rail AC-DC power supply |
| Number of Outputs | 1 |
| Input Phase | Single phase |
| AC Input Voltage | 90 to 264VAC |
| DC Input Voltage | 120 to 375VDC |
| Input Frequency | 47 to 63Hz |
| Nominal Output Voltage | 12VDC |
| Rated Output Current | 1.5A |
| Rated Output Power | 18W |
| Typical Efficiency | 77% |
| Ripple and Noise | Approximately 50mV peak-to-peak |
| Isolation Voltage | 3,000VAC input to output |
| Operating Temperature | -20 to +71°C, subject to output derating at elevated temperatures |
| Cooling Method | Natural convection |
| Degree of Protection | IP20 |
| Connections | Spring-clamp terminals |
| Enclosure Material | Plastic |
| Dimensions | 90 x 22.5 x 114mm |
| Weight | Approximately 150g |
| Mounting | 35mm DIN rail |
| Compliance Standards | UL 508, UL/EN 62368-1, EN 55032, TUV and CE |
| Warranty | 3 years |
Available Model
This product page covers only the 12V spring-clamp terminal version of the Chinfa DRA18 series.
| Model Number | Input Voltage | Output Voltage | Output Current | Power Rating |
|---|---|---|---|---|
| DRA18-12 | 90-264VAC / 120-375VDC | 12VDC | 1.5A | 18W |
